G3 Efficient Gas Insert
G3 Efficient Gas Insert
The G3 was first introduced by Valor in 1991 as part of their flagship line and has been exceeding customer expectations ever since. Innovation, attention to detail and continuous improvement have positioned the G3 as the industry’s number one selling radiant gas insert.
Easy-to-use, energy saving features make the G3 insert a true leader in efficient, effective zone heating.
Valor inserts provide peak performance and improved operating efficiencies—saving you energy with AutoFire™.
Fuel Beds
739DWK I Driftwood
739LSK I Logs
739RSK I Rocks
761DRK I Decorative Rocks
Liners
739FBL I Fluted Black
739RGL I Reflective Glass
739VRL I Red Brick
Fronts
741SFB
Contemporary Front - Black
741SVI
Contemporary Front - Vintage Iron
742CFB
Cast Iron Front - Black
743FVI
FenderFire Double Door Front
744FVI
FenderFire Single Door Front
745CFV
Clearview Front - Vintage Iron (choose Fret option)
765CSB
Contemporary Surround Front - Black (739 engine only)
765CSC
Contemporary Surround Front - Copper (739 engine only)
765CSN
Contemporary Surround Front - Brushed Nickel (739 engine only)
765CSPN
Contemporary Surround Front - Painted Nickel (739 engine only)
772MBF2
Matte Black Front (739 engine only)
| Model | Max Input | Min Input | Max Output | Energuide |
|---|---|---|---|---|
| 738KN | 24,000 | 6,500 | 16,169 | 61.20% |
| 738KP | 24,000 | 13,000 | 16,169 | 61.20% |
| 739MN | 24,000 | 6,500 | 18,132 | 70.30% |
| 739MP | 24,000 | 13,000 | 18,132 | 70.30% |
| Gas Type | Natural Gas (NG) or Propane (LPG) |
| Remote Control | Quick Guide | Manual |
| Viewing Area | 26 ⅛” w x 12 ⅛” h = 317″² |
| Min. Cavity Dimensions | 28″ w x 20″ h x 12″ d |
| Wall Control | 1265WSK |
| Installation Type | Direct Vent or B-Vent |
| ValorStat Plus | ValorStat Plus Remote Manual and Quick Guide |
Frets
740CAP
Clearview Access Panel
758CCB
Clearview Cast Fret
1225VFB
Ventana Fret
Optional Backing Plates / Closure Plates
763BPB
Backing Plate - Black
750OCP
Oversized Closure Plate - Black
750OVI
Oversized Closure Plate - Vintage Iron
| 559CLT | Co-Linear Terminal |
| 559SFK | Square Flashing Kit (for use with 559CLT) |
| 720SWK | Co-Linear Side Wall Kit (for use with 739J engine) |
| 720SWK-M | Co-Linear Side Wall Kit (for use with 739M engine) |
| 725RTB | Riser Kit – Black – 40″ w x 2 ½” h |
| 751LTK | Lift Trim Kit – Black (must be used with 752BTK/BVK) |
| 751LVK | Lift Trim Kit – Vintage Iron (must be used with 752BTK/BVK) |
| 752BTK | Base Trim Kit – Black |
| 752BVK | Base Trim Kit – Vintage Iron |
| 755CFK | Circulating Fan Kit (739 engine only) |
| 761DRK | Decorative Rock Kit (addition to 739RSK) |
| 762TRB | Temperature Reduction Baffle |
| GV60BRK | 1-Hour Shut Down Handset (739 engine only) |
| GV60NTK | Non-Thermostat Handset (739 engine only) |
| GV60PAK | Power Adapter Kit (739 engine only) |
